BALL JOINT | JIKIU - JB21118

Specification

Thread Size:

M14x1.50

Cone Pitch:

1:6

Cone Size Ø (mm):

17.6

Overall Height (mm):

88

Ø (mm):

42.7

Mounting Height (mm):

56

Location

Front Axle Arm/Rod

Position

Lower Left/Right

Parent Assembly

Brands

JIKIU

JIKIU

Type

ARM ASSY, SUSPENSION

ARM ASSY, SUSPENSION

Crosses

Owner
Number
555 SANKEI
SBT-112
CTR
CB0434
CTR
CBT-91
FeBest
0120-N60
LYNXauto
C1228LR
TOYOTA
43308-29255
TOYOTA
48068-29235_JB
Owner
Number
TOYOTA
48068-29265_JB
TOYOTA
48069-29235_JB
TOYOTA
48069-29255_JB
TOYOTA
48069-29255_JC
TOYOTA
48069-29265_JB
