BALL JOINT | JIKIU - JB24311

Specification

Thread Size:

M14x1.50

Cone Pitch:

1:8

Cone Size Ø (mm):

17.5

Ø (mm):

n/a

Overall Height (mm):

94.6

Mounting Height (mm):

58

Location

Front Axle Arm/Rod

Position

Upper Left/Right

Parent Assembly

Brands

JIKIU

JIKIU

Type

ARM ASSY, SUSPENSION

ARM ASSY, SUSPENSION

Crosses

Owner
Number
555 SANKEI
SB5311
CTR
CB0153
CTR
CBIS-17
FeBest
3020-001
GREAT WALL
2904130-K00
GREAT WALL
894374424
ISUZU
8-94374-424-0
ISUZU
8-94374-424-1
Owner
Number
ISUZU
8-94374-424-2
ISUZU
8-94374-424-4
ISUZU
8-97365-019-0
ISUZU
8-97365-019-1
ISUZU
8-98005-826-0
LYNXauto
C1103LR
