TIE ROD END | JIKIU - ET25731

Specification

Mounting Length (mm):

85.5

Thread (in/out)

M14x1.5 RHT

Cone Size Ø(mm) :

14.9

Cone Pitch:

1:8

Thread (Cone out)

M12x1.25

Overall Height (mm):

76.5

Mounting Height (mm):

39.5

Full Lenght (mm):

106

Location

Steering system

Position

Left/Right

Sub Assembly

Brands

JIKIU

Part

Type

TIE ROD END BOOT

Couple

Number

Crosses

Owner

Number

555 SANKEI

SE1731

CTR

CE0483

CTR

CEMZ-63

FeBest

0521-BT50OUT

Owner

Number

FORD

1 454 898

MAZDA

UH76-32-280

MAZDA

UR61-32-280
