TIE ROD END | JIKIU - ET25771L

Specification

Mounting Length (mm):

206

Thread (in/out)

M14x1.5 RHT

Cone Size Ø(mm) :

14.9

Thread (Cone out)

M12x1.25

Cone Pitch:

1:8

Mounting Height (mm):

40.5

Full Lenght (mm):

225

Overall Height (mm):

77

Location

Steering system

Position

Left

Couple

Number

Crosses

Owner

Number

555 SANKEI

SE1771L

CTR

CE0473

CTR

CEMZ-53

FeBest

0521-ERLH

LYNXauto

C4298L

MAZDA

EG21-32-290

Owner

Number

MAZDA

EG21-32-290A

MAZDA

EG21-32-290B

MAZDA

TD11-32-290

MAZDA

TD11-32-290A
