TIE ROD END | JIKIU - ET21181L
Specification
Mounting Length (mm):
210
Thread (in/out)
M22x1.5 RHT
Cone Size Ø(mm) :
18.56
Thread (Cone out)
M16x1.50
Cone Pitch:
1:10
Mounting Height (mm):
40
Full Lenght (mm):
230
Overall Height (mm):
90
Location
Steering system
Position
Left
Note
TUNDRA 07~ SEQUOIA 08~
Crosses
Owner
Number
555 SANKEI
SE-T181L
Blue Print
ADT387243
CTR
CE0790
CTR
CET-175
Owner
Number
LYNXauto
C4437L
SWAG
81 94 8243
TOYOTA
45047-09260
