TIE ROD END | JIKIU - ET26881
Specification
Mounting Length (mm):
83.5
Thread (in/out)
M15x1.50
Cone Size Ø(mm) :
13.4
Thread (Cone out)
M12x1.25
Cone Pitch:
1:6
Mounting Height (mm):
33.5
Full Lenght (mm):
101.5
Overall Height (mm):
76.5
Location
Steering system
Position
Left/Right
Crosses
Owner
Number
555 SANKEI
SE-3881
CTR
CE0761
CTR
CET-146
JAE
53540-1013G
LYNXauto
C4120LR
TOYOTA
45046-09250
TOYOTA
45046-09251
Owner
Number
TOYOTA
45046-09260
TOYOTA
45046-09261
TOYOTA
45046-09320
TOYOTA
45046-09330
TOYOTA
45046-09780
TOYOTA
4504609840
