TIE ROD END | JIKIU - ET24361

Specification

Mounting Length (mm):

80

Thread (in/out)

M14x1.5 RHT

Cone Size Ø(mm) :

16

Cone Pitch:

1:8

Thread (Cone out)

M14x1.50

Overall Height (mm):

76

Full Lenght (mm):

102

Mounting Height (mm):

36

Location

Steering system

Position

Left/Right

Crosses

Owner
Number
555 SANKEI
SE-5361
Ashika
111-09-915
Blue Print
ADZ98727
CTR
CE0264
CTR
CEIS-25
ISUZU
8-97304-855-0
ISUZU
8-97304-928-0
Owner
Number
ISUZU
8-97945-434-0
ISUZU
8-98055-746-0
ISUZU
8-98056-551-0
JIKIU
ET24381
SWAG
13 94 3360
