TIE ROD END | JIKIU - ET28024

Specification

Thread (in/out)

M14x1.5 RHT

Cone Pitch:

1:8

Thread (Cone out)

M12x1.25

Mounting Length (mm):

105

Cone Size Ø(mm) :

14.5

Mounting Height (mm):

38

Full Lenght (mm):

127

Overall Height (mm):

80

Location

Steering system

Position

Left/Right

Crosses

Owner

Number

555 SANKEI

SE-H411

CTR

CE0200

CTR

CEHO-14

FeBest

0321-RL1

Owner

Number

HONDA

53540-S0X-A01

HONDA

53540-S0X-A02
