WHEEL HUB | JIKIU - HW11024
Specification
w/ ABS
YES
Flange Ø (mm)
138
Rim-Hole (pcs)
5
Centering Diameter
76
Outer Ø (mm)
72.85
Height (mm)
59
Teeth ABS Quant.:
47
Bolt Hole Circle Ø (mm)
114.3
Inner Ø (mm) OR inn Teeth
n/a
Location
Rear Axle Transmission
Position
Left/Right
Sub Assembly
Crosses
Owner
Number
ASVA
HYWH-A5RA47
BENDIX
052107B
FAG
713 6268 50
HYUNDAI
52710-3X000
HYUNDAI / KIA
52710-3X100
ILJIN
IJ113044
KIA
52710-3X000
Owner
Number
KIA
52710-3X100
LYNXauto
WH-1487
Meyle
37-14 752 0018
MOOG
HY-WB-12823
SKF
VKBA 7625
