TIE ROD END | JIKIU - ET11048L

Specification

Thread (in/out)

M14x1.5 RHT

Cone Pitch:

1:8

Cone Size Ø(mm) :

13.4

Thread (Cone out)

M10x1.25

Mounting Length (mm):

189

Mounting Height (mm):

32

Full Lenght (mm):

208.7

Overall Height (mm):

71

Location

Steering system

Position

Left

Couple

Number

ET11048R

Crosses

Owner
Number
555 SANKEI
SEK-8081L
CTR
CE0328L
CTR
CE0328LA
CTR
CEKH-36L
CTR
CEKK-31L
HYUNDAI
56820-1E000
Owner
Number
HYUNDAI
56820-1G900
HYUNDAI / KIA
568201E000
JRAPP
A1429
KIA
56820-1G900
LYNXauto
C4165L
