TIE ROD END | JIKIU - ET13005L

Specification

Mounting Length (mm):

200

Thread (in/out)

M16x1.5 RHT

Cone Pitch:

1:8

Cone Size Ø(mm) :

13.4

Thread (Cone out)

M10x1.25

Mounting Height (mm):

32

Full Lenght (mm):

218

Overall Height (mm):

70.4

Location

Steering system

Position

Left

Sub Assembly

Brands

JIKIU

Part

CE13002

Type

TIE ROD END BOOT

Couple

Number

ET13005R

Crosses

Owner
Number
CTR
CE0372L
CTR
CEKK-38L
FeBest
2221-CA7LH
HYUNDAI / KIA
56820-A7000
HYUNDAI / KIA
56820-B0000
HYUNDAI / KIA
56820A7500
Owner
Number
KIA
56820-A7000
KIA
56820-A7500
LYNXauto
C4429L
Mando
DSA020536
MOOG
KI-ES-17009
