WHEEL HUB | JIKIU - HW13012
Specification
Inner Ø (mm) OR inn Teeth
27
Centering Diameter
69
Outer Ø (mm)
42
Flange Ø (mm)
139
Height (mm)
57
Rim-Hole (pcs)
5
Bolt Hole Circle Ø (mm)
114.3
w/ ABS
NO
Teeth ABS Quant.:
n/a
Location
Front Axle Transmission
Position
Left/Right
Note
KIA SOUL 2010-2014
Sub Assembly
Crosses
Owner
Number
ASVA
KAWH-B2F
BENDIX
052453B
BTA
H50513BTA
BTA
H50524BTA
HYUNDAI
51750-1P000
JIKIU
HW11033
KIA
51750-1P000
KIA
51750-2K000
Owner
Number
KIA
51750-A5000
NTY
KLP-HY-524P
Optimal
04-P473
PATRON
PBK4527H
SAT
ST-51750-A5000
TRIALLI
MR 0810
