WHEEL HUB | JIKIU - HW53011
Specification
Flange Ø (mm)
142
Rim-Hole (pcs)
5
Bolt Hole Circle Ø (mm)
114.3
w/ ABS
YES
Teeth ABS Quant.:
Magnet
Inner Ø (mm) OR inn Teeth
32
Centering Diameter
69
Outer Ø (mm)
85
Height (mm)
48.5
Location
Front Axle Transmission
Position
Left/Right
Note
Teeth number , ABS ring: 86
Sub Assembly
Crosses
Owner
Number
CHRYSLER
05085 406AB
CHRYSLER
05085 406AC
CHRYSLER
05154 211AA
CHRYSLER
5085406AC
Owner
Number
CONCORD
HB1-0060
FeBest
2082-AVENF
MOOG
513263
