Catalogue Search
TIE ROD END | JIKIU - ET24321L
Specification
Mounting Length (mm):
87
Thread (in/out)
M20x1.5 LHT OUT
Thread (Cone out)
M16x1.50
Cone Size Ø(mm) :
17.85
Cone Pitch:
1:8
Overall Height (mm):
99
Mounting Height (mm):
48.5
Full Lenght (mm):
108
Location
Steering system
Position
Left
Crosses
Owner
Number
555 SANKEI
SE5321L
CTR
CE0262
CTR
CEIS-23
ISUZU
8-97039-463-0
ISUZU
8-971047-349-0
ISUZU
8-971047-349-2
ISUZU
8-97107-349-0
Owner
Number
ISUZU
8-97107-349-1
ISUZU
8-97107-349-2
ISUZU
8-97142-101-1
ISUZU
8-97222-510-0
LYNXauto
C4333L
