TIE ROD END | JIKIU - ET24321R
Specification
Mounting Length (mm):
87
Thread (in/out)
M20x1.5 RHT OUT
Thread (Cone out)
M16x1.50
Cone Size Ø(mm) :
17.85
Cone Pitch:
1:8
Overall Height (mm):
99
Mounting Height (mm):
48.5
Full Lenght (mm):
108
Location
Steering system
Position
Right
Crosses
Owner
Number
555 SANKEI
SE-5321R
CTR
CE0261
CTR
CEIS-22
ISUZU
8-97039-462-0
ISUZU
8-97107-348-0
ISUZU
8-97107-348-1
Owner
Number
ISUZU
8-97107-348-2
ISUZU
8-97142-100-1
ISUZU
8-97222-509-0
LYNXauto
C4333R
